Clear Reinforced PVC Hose for Standard Ring Vacs
Reinforced clear polyvinyl chloride (PVC) Hose designed for a full view of product flow and higher working pressures, and it is an accessory option for use with the Standard Ring Vacs.
Clear Reinforced PVC Hose for Standard Ring Vacs
Reinforcing clear polyvinyl chloride Hose designing for viewing product flow fully. Creating higher working pressures is an accessory option using the Standard Ring Vacs.
Remember that the tubing is FDA-approved. They are making the product usable in applications where the Ring Vac air-operated conveyors convey food or medical products.
Understanding Hose ratings
- are good to excellent for acids, fair to alkalis, and ideal for most solvents.
Accomplished by clamping the hose to each end of the Ring vac. Giving us approximately 1/3rd of the total distance conveyed at the inlet side. On the outlet, the side is 2/3rd of the length, Providing optional clamps can be provided. Also, supplied by the customer securing the hose to the Ring vac air-operated conveyor.
Remember that various standard hose lengths are available for purchase and cut to size at the destination.
Also, you are making It crucial to minimize the number of bends used for conveying to minimize back pressure and maximize the distance your product can convey.
Additionally, any bends should be at such an angle that any long product feeding into the Ring vac for conveying does not get jammed around any bend because it is too angled.
Finally, the Ring vac air-operated conveyor with an attached PVC hose works effectively and with long life.
| Weight | N/A |
|---|---|
| Size | 1/2", 3/4", 1", 1-1/4", 1-1/2", 2" |
| Length | 10 ft, 20 ft, 30 ft, 40 ft, 50 ft |
| SKU | Size | Length | ||
|---|---|---|---|---|
| 39999H10 | 1/2" | 10 ft | ||
| 39999H20 | 1/2" | 20 ft | ||
| 39999H30 | 1/2" | 30 ft | ||
| 39999H40 | 1/2" | 40 ft | ||
| 39999H50 | 1/2" | 50 ft | ||
| 30000H10 | 3/4" | 10 ft | ||
| 30000H20 | 3/4" | 20 ft | ||
| 30000H30 | 3/4" | 30 ft | ||
| 30000H40 | 3/4" | 40 ft | ||
| 30000H50 | 3/4" | 50 ft | ||
| 30001H10 | 1" | 10 ft | ||
| 30001H20 | 1" | 20 ft | ||
| 30001H30 | 1" | 30 ft | ||
| 30001H40 | 1" | 40 ft | ||
| 30001H50 | 1" | 50 ft | ||
| 30002H10 | 1-1/4" | 10 ft | ||
| 30002H20 | 1-1/4" | 20 ft | ||
| 30002H30 | 1-1/4" | 30 ft | ||
| 30002H40 | 1-1/4" | 40 ft | ||
| 30002H50 | 1-1/4" | 50 ft | ||
| 30003H10 | 1-1/2" | 10 ft | ||
| 30003H20 | 1-1/2" | 20 ft | ||
| 30003H30 | 1-1/2" | 30 ft | ||
| 30003H40 | 1-1/2" | 40 ft | ||
| 30003H50 | 1-1/2" | 50 ft | ||
| 30004H10 | 2" | 10 ft | ||
| 30004H20 | 2" | 20 ft | ||
| 30004H30 | 2" | 30 ft | ||
| 30004H40 | 2" | 40 ft | ||
| 30004H50 | 2" | 50 ft |
